46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

Product Categories
Shenzhen YOMURA Display Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

Model Number : 624655S3

Certification : CE RoHS CCC FCC ISO9001

Place of Origin : China

MOQ : 4

Price : $ 312 - 410 / Unit

Payment Terms : T/T,D/A,L/C,D/P,Western Union

Supply Ability : Over 30000 Units / Month

Delivery Time : 3-15 Work Days

Packaging Details : Standard Carton with Foam Cushioning

Brand Name : YOMURA

Lcd Panel : A-si TFT LCD panel

Screen Size : 46 55 inches

Bezel Width : 1.7 mm

Resolution Ratio : 1920(RGB)×1080, FHD

Ratio : 16:9

Chromatic Number : 8Bit 16.7M

Refresh Rate : 60Hz

Rated Power : ≤175W

Backlight Type : DLED

Brightness : 450 cd/m² (Typ.)

Contact Now

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

Professional-grade 55-inch LCD display panel, specifically engineered for ultra-seamless video wall installations. Featuring an ultra-narrow bezel width of just 1.7mm and built with industrial-grade reliability, it is ideal for control rooms, corporate lobbies, and digital signage. The panel supports flexible configurations such as 2x2, 3x3, and larger MxN matrix arrangements to create expansive, high-impact visual displays.

1. Product Overview

Item Specification
Screen Size 55 inch (46-inch model details not in this sheet, but may be available in the product line)
Bezel Width (Seam) 1.7mm
Panel Technology A-si TFT-LCD, IPS
Aspect Ratio 16:9
Surface Treatment Matte anti-glare

✅ 2. Display Parameters

Parameter Value / Description
Resolution 1920 × 1080 (FHD)
Brightness 500 cd/m² (Typ.)
Contrast Ratio 4500:1 (Typ.)
Color Depth 8bit, 16.7M colors
Color Gamut sRGB 98%, NTSC 75%
Pixel Pitch 0.63mm × 0.63mm (~40 PPI)
Viewing Angle 178° (H) / 178° (V)
Response Time 8ms (G to G)
Refresh Rate 60Hz
Backlight Type DLED (Direct LED)
Default Color Temperature 6500K
Lifespan 50,000 hours

✅ 3. Interfaces & Control

Type Interface / Function Description
Input HDMI ×1 Supports up to 3840×2160@30Hz, 10bit/8bit color formats
RJ45 (Network) ×1 Compatible with Nova Es series / NMX matrix; max. 50m transmission @1080p60
Control RS232 IN ×1 (RJ45) For PC control or IR receiver connection
RS232 OUT ×2 (RJ45) For daisy-chain control or signal loop-out
Other USB ×1 Firmware update / USB media playback
Remote Infrared Remote Effective distance <10 meters

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen

46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen
